TEAC A-100

Stereo Cassette Deck (1977)

Description

Features of the A-100 include Dolby noise reduction, DC servo controlled motor, individual dual position bias and equalization selectors, timer control function, lighted cassette compartment, digital tape counter, front panel microphone inputs, two VU type loudness meters and a stereo headphone jack.

Specifications

Type: 2-head, single compact cassette deck

Track System: 4-track, 2-channel stereo

Tape Speed: 4.76 cm/s

Heads: 1 x record/playback, 1 x erase

Motor: DC servo controlled

Tape Type: type I, CrO2

Noise Reduction: B

Frequency Response: 30Hz to 14kHz  (Cr02 tape)

Signal to Noise Ratio: 55dB  (dolby B)

Wow and Flutter: 0.1%

Input: 60mV (line), 0.25mV (mic)

Dimensions: 160 x 410 x 300mm
