Pioneer SX-626

AM/FM Stereo Receiver (1972-74)

Description

A medium-powered stereo receiver with up to 110 watts of music power, low-noise FET, and high sensitivity FM tuner section.

The SX-626 stereo receiver is one of Pioneer's great stereo values. In one attractive, well-designed package, it offers the hi-fi enthusiast everything he could possibly desire in a medium-range power unit.

Including up to 110 watts of power (at 4 ohms), an FM tuner section of excellent selectivity and sensitivity, high signal-to-noise ratio, and two tape monitor circuits that permits tape-to-tape duplicating.

The SX-626 is powerful enough to operate a pair of large speakers, yet it's also versatile enough to handle small- and medium-range speakers for the man who's investment in stereo must be budgeted.

Specifications

Tuning range: FM, MW

Power output: 20 watts per channel into 8Ω (stereo)

Frequency response: 5Hz to 80kHz

Total harmonic distortion: 1%

Damping factor: 40

Input sensitivity: 2.2mV (mic), 2.5mV (MM), 200mV (DIN), 200mV (line)

Signal to noise ratio: 85dB (MM), 95dB (line)

Output: 200mV (line), 35mV (DIN)

Speaker load impedance: 4Ω to 16Ω

Semiconductors: 4 x FET, 4 x IC, 41 x transistors, 22 x diodes

Dimensions: 450 x 145 x 360mm

Weight: 9.9kg
