Pioneer PL-A35

Fully-Automatic Belt-Drive Turntable (1971-1974)

Description

The PL-A35 combines studio quality performance with the operational ease of a fully automatic.

Simply flick the function lever to the Start position once, and the tonearm will be automatically moved over and lowered onto the record and, at the end of the disc, will return to its rest.

One touch Cue and Repeat features let you interrupt and repeat any record freely.

The platter is driven by a synchronous 4-pole motor of excellent stability independent from power voltage fluctuations.

The belt drive is precision finished on both sides, a feature that helps reduce wow and flutter to an absolute minimum (the tonearm is moved by a separate, geared motor).

Specifications

Type: fully automatic turntable

Drive method: belt drive

Motor: 4-pole synchronous

Speeds: 33 and 45rpm

Speed accuracy: 1%

Wow and flutter: 0.1% WRMS

Signal to noise ratio: 47dB

Platter: 300mm aluminium alloy

Tonearm: static balance type, pipe arm (s-shaped)

Effective length: 221mm

Usable cartridge weight: 4 to 10g

Dimensions: 480 x 415 x 183mm

Weight: 9kg
