Onkyo A-7090

Super Servo Operation Integrated Stereo Amplifier (1980-81)

Specifications

Power output: 110 watts per channel into 8Ω (stereo)

Frequency response: 10Hz to 50kHz

Total harmonic distortion: 0.01%

Damping factor: 50

Input sensitivity: 0.25mV (MC), 2.5mV (MM), 150mV (line)

Signal to noise ratio: 68dB (MC), 78dB (MM), 90dB (line)

Output: 150mV (line), 1.5V (Pre out)

Speaker load impedance: 4Ω to 16Ω

Semiconductors: 8 x FET, 74 x transistors, 41 x diodes, 6 x IC

Dimensions: 418 x 155 x 410mm

Weight: 18kg
