NO SHIPPING - LOCAL PICKUP ONLY



Luxman PX-101

Fully-Automatic Tangential Tracking Turntable (1982-1985)

Description

The PX-101 plays back records exactly as they were cut: in a straight line. Essentially, providing zero deviation from the cutting process, as well as zero tracking error and zero tracking distortion during playback.

The advantages of tangential tracking are immediately evident. The music sounds cleaner, with better separation between channels, better separation of instruments within the orchestra, and a far more vivid recreation of the sound stage.

With the PX-101, wow and flutter is inaudible. Rumble, non existent.

Both the tonearm and headshell are constructed of improved aluminium alloy for resonance control and damping.

Fully automatic, direct drive, it requires but a touch to operate. A built-in circuit of the PX-101 will automatically place your accompanying Luxman KX-101 or KX-102 Cassette Deck in the pause mode when the record you're recording has reached the end of play.

And the PX-101 is also responsive to the Infra-red Wireless Remote Control system of the new Luxman RX-103 Receiver. The PX-101 - every inch, a Luxman.

Specifications

Driving system: direct drive system

Motor: brushless and slotless DC servo motor

Platter: 295mm aluminium diecast

Speeds: 33 and 45rpm

Pitch control: +-3%

Signal to noise ratio: better than 70dB

Wow and flutter: no more than 0.045% WRMS

Tonearm: straight arm of static balance type

Effective length: 165mm

Cartridge weight: 5.5-10g

Cartridge height: 16-19mm

Stylus pressure: 0-3g

Dimensions: 440 x 115 x 405mm

Weight: 8.5kg
