Kenwood KX-660HX Stereo Cassette Deck

General

• Manufacturer: Kenwood
• Model: KX-660 HX
• Type: Compact Cassette Tape Deck
• Type: Front loader
• Years of manufacture: 1987 - 1989
• Made in: Japan
• Color: Black
• Remote control: no
• Mains connection: 220 V / 50 Hz
• Power consumption:
• Dimensions: 440 x 113 x 323 mm (WxHxD).
• Weight: 5 kg
• Original price approx.: 598 DM

Connections

• Signal inputs:
  • Line RCA Cinch R+L
  • Microphone 6.35 mm jack R+L
• Signal outputs:
  • Line RCA R+L
  • Headphone 6,35 mm (without level control)

Technical Data

• Tone heads: Hard Permalloy A/W
• Motors: 2
• Synchronous fluctuations: 0.06% WRMS, 0.16% DIN
• Tape types: IEC Type I / II / IV
• Frequency range:
  • 20 - 16000 Hz ±3 dB Type I.

20 - 17000 Hz ±3 dB Type II

• • 20 - 18000 Hz ±3 dB Type IV
• Distortion factor: < 0.9%
• Signal-to-noise ratio: 59 - 74 dB
• Auto Reverse: No
• Title search: Yes
• Noise reduction Dolby B, C
• Dynamic enhancement Dolby HX-Pro
• MPX Filter:
• Fader:
• Pitch Control:
• CD Synchro Recording:

Special Features

• Bias setting
• Timer operation
