JVC JR-S201

DC Integrated Receiver (1978)

Description

With the same stunning styling and same reliable performance as the more expensive models, the JR-S201 with it's lower power output and correspondingly lower price is not a no-frills receiver by any measure.

Power output is a comfortable 35 watts per channel and you get our DC amplifier technology, SEA graphic equaliser, and other admirable advantages to ensure you get your pleasure's worth over long years of use.

Specifications

Tuning range: FM, MW

Power output: 35 watts per channel into 8Ω (stereo)

Frequency response: 5Hz to 40kHz

Total harmonic distortion: 0.01%

Damping factor: 70

Input sensitivity: 2.5mV (MM), 150mV (line)

Signal to noise ratio: 75dB (MM), 95dB (line)

Output: 150mV (line), 30mV (DIN)

Speaker load impedance: 4Ω to 16Ω

Dimensions: 166 x 500 x 378mm

Weight: 10.6kg

Year: 1978
