The Story
*Reels not included
Akai X-1810D
Reel to Reel / Cartridge Combination Tape Recorder (1973)
SpecificationsTrack system: 4-track, 2-channel, stereo/monaural system
Heads: 1 x record/playback, 1 x erase, 1 x bias
Motor: 2 x reel drive, 1 x capstan
Reel size: 5 or 7 inch reel
Equalization: NAB
Tape speeds: 1 7⁄8 3 3⁄4 7 1⁄2 ips
Wow and flutter: 0.08% (7 1⁄2 ips)
Frequency response: 30Hz to 22kHz (7 1⁄2 ips)
Signal to Noise Ratio: 50dB
Total harmonic distortion: 2%
Crosstalk: 45dB
Input: 60mV (line), 20mV (DIN), 0.5mV (mic)
Output: 1.23V (line), 1.23V (DIN)
Semiconductors: 17 x transistors, 15 x diodes
Dimensions: 435 x 450 x 240mm
Weight: 20kg
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
*Reels not included
Akai X-1810D
Reel to Reel / Cartridge Combination Tape Recorder (1973)
SpecificationsTrack system: 4-track, 2-channel, stereo/monaural system
Heads: 1 x record/playback, 1 x erase, 1 x bias
Motor: 2 x reel drive, 1 x capstan
Reel size: 5 or 7 inch reel
Equalization: NAB
Tape speeds: 1 7⁄8 3 3⁄4 7 1⁄2 ips
Wow and flutter: 0.08% (7 1⁄2 ips)
Frequency response: 30Hz to 22kHz (7 1⁄2 ips)
Signal to Noise Ratio: 50dB
Total harmonic distortion: 2%
Crosstalk: 45dB
Input: 60mV (line), 20mV (DIN), 0.5mV (mic)
Output: 1.23V (line), 1.23V (DIN)
Semiconductors: 17 x transistors, 15 x diodes
Dimensions: 435 x 450 x 240mm
Weight: 20kg
